Batiri Intemal Resistance Sɛgɛsɛgɛlikɛlan

Minɛnw jɔcogo

Minɛnw ka kanw hakɛ

Masina bɛɛ lajɛlen bɛ ni kan 512 ye

Chassis kulɛri

Standard gris noir (a bɛ se ka kɛ ka kɛɲɛ ni mɔgɔw sago ye) .

Fixture foroko

Kungolo fla fixture

Fixture (fiɲɛbɔlanw) cɛ janya.

35mm ye

Kanal ɲɛminɛcogo

Batiri kelen-kelen bɛɛ bɛ ni kuran sabatilen yɛrɛmahɔrɔnyalen ye ani tension basigilen sɔrɔyɔrɔ, o min bɛ sabati ni a ma tiɲɛ. A daminɛ, a jɔ, a jɔ, a bɛ taa ɲɛ ani lakanani bɛ se ka kɛ.

Kanal kelen-kelen bɛɛ ka chargement current ni discharge current accuracy bɛ se ka calibre automatiquement software fɛ.

Kanal kelen-kelen bɛɛ bɛ ni tension constant (voltage constant) yɛrɛmahɔrɔnyalenw ye ani current constant (kurun basigilen) hardware control circuits

Baarakɛ kuran dilancogo

Fasa saba duuru ka fili AC380V, 10%, 50Hz

Seko ni dɔnko factor

0.99@220VAC, A bɛ doni dafalen na, Kuran sira THDu A ka dɔgɔn walima a bɛ bɛn 2% ma

Ɔridinatɛri ka Harmoniki

<5%@220VAC, Fully loaded, Power grid THDu ≤2%

Kuranko baarakɛcogo ɲuman jiralan

Charge min ka bon walima min bɛ bɛn 80% ma, Discharging min ka bon walima min bɛ bɛn 70% ma

Baara fanga tacogo

A ka dɔgɔn walima a bɛ bɛn 22KW ma

Minɛnw tiɲɛni hakɛ

<1%

Baara fanga tacogo

Natural dondaw ni bɔli

Seko ni dɔnko yɔrɔw lakanani

baarakunda

Kuran rezow ka tension dantɛmɛnen lakanani Kuran rezow frequency overrun lakanani

Kanal paramɛtiriw

Voltage sumanikɛlan hakɛ

DC 0 ~ 5V ye

Batiri ka wulicogo hakɛ

Charge DC 0 ~ 4,5V; Discharge DC 4,5 ka se 2V ma

Voltage (voltaji) hakɛ basigilen

DC 2 ~ 4,5V ye

Voltage (voltaji) tiɲɛni

+(0,05% kalanni +0.05% degeli dafalen)

Voltage control (voltaji) ɲɛnabɔli ɲɛnabɔli

1mV ye

Voltage sampling ɲɛnabɔli

1mV ye

Sisan range (yɔrɔ) min bɛ yen

Chargement Dc 12mA ~ 6A ye; Discharge DC 12mA ~ 6A

Sisan tiɲɛni

+(0,05% kalanni +0.05% degeli dafalen)

Sisan kuntigiya ɲɛnabɔli

1mA ye

Sisan misali tacogo ɲɛnabɔli

1mA ye

Sisan wuli waati (90% doni) .

A ka dɔgɔn walima a bɛ bɛn 50MS ma

Kanal daminɛ waati (90% doni) .

A ka dɔgɔn walima a bɛ bɛn 50MS ma

Porozɛw baarakɛcogo

Kontrɔli cogoya

ɔridinatɛri kɔlɔsili minɛnw baara, kabini bɛɛ kɔlɔsili, ni scanning system ye

Kumaɲɔgɔnya kɛcogo

485 Seriyali port kumaɲɔgɔnya (baud rate 57600)/TCPcommunication

Taabolo Setup (Taabolo Setup).

Aw bɛ se ka baara kɛcogo 32 ni cycle 256 sigi sen kan

Chargement cogoya

Kuran basigilen, tension basigilen, kuran basigilen ani tension basigilen

Charge tigɛ-off cogoya

Voltage, current, waati, seko,-AV

Jibɔcogo

Kuran basigilen, fanga basigilen, resistance basigilen

Discharge tigɛ-off cogoya

Voltage, waati, seko

Lakanali fɛnw

1. Charging overvoltage lakanani, chargingundervoltage lakanani

2 bɔli tension overvoltage lakanani, dischargeundervoltage lakanani

3. Charge ni discharge voltage trend lakanani

4. Voltage jiginni lakanani

5. Sisan jiginni lakanani

6. Batiri kɔkanna lakanani, fɛnɲɛnamafagalan lakanani

7. Seko ni dɔnko tubabu surun-circuit lakanani

8.Channel seko alarma lakanani (waati tɛmɛnen lakanani) .

9. Voltage sampling off-layini lakanani

10. Voltage outlier lakanani

11.Seko ni dɔnko outlier lakanani

12. Aw bɛ degun dɔnni da wuli sani baara ka daminɛ, ka kanal da wuli min ka tansiyɔn tɛmɛna dan kan

13.Power off lakanani, data breakpoint seginni

Waati dantigɛli

0 fo miniti 3000/baara taabolo, waati hakɛ ye min ye

Waati tiɲɛni

A ka dɔgɔn walima a bɛ bɛn ±1‰ ma .

Sampling sɛgɛsɛgɛli cycle (sɛgɛsɛgɛli kɛcogo).

1S-60S A bɛ se ka kɛ

Batiriw sɛgɛsɛgɛli

Sort by (seko, waati, da wulilen tension, dischargeplatform, a ɲɔgɔnnaw)

Donanw baaracogo

A bɛ se ka tension, current, time, capacity data sɛbɛn automatiquement ka charge constant current charge ratio,capacity loss, discharge efficiency, moyenne voltage,median voltage ani data wɛrɛw sɛbɛn, ani ka data curvesand cycle diagrams di Bɔli ka sɛbɛnni, EXCELWODR walima MDB database format files dilan

Porozɛw baarakɛcogo jɔnjɔnw

1. porogaramu bɛ dɛmɛ don kurayali suguya caman na, i n’a fɔ bololabaarakɛlaw ka jɔli kurayali, porogaramuw dabilacogo kurayali, kuran tiɲɛni kurayali, minɛnw ka kumaɲɔgɔnya tiɲɛni kurayali, jɔli kurayali min tɛ cogo la

2. dɛmɛn bar code scanning, kelen-dimension code,fila{2}}dimension code scanning, sequentialscanning code, kanal jump scanning code, platescanning code ani scanning fɛɛrɛ wɛrɛw bɛ yen

.

4. Dɛmɛ seko ni dɔnko sɛgɛsɛgɛli, min bɛ se ka jate batiri kan;

5. ka tɛmɛsira kiritigɛ dɛmɛ sɛgɛsɛgɛli laban na, ka kɛɲɛ ni cycle seko, tension, waati ani kunnafoni wɛrɛw kofɔlen ye walasa ka Pass/NG jaabiw jateminɛ ;

6. dɛmɛ suguya caman baara senfɛ lakanani ani globalvoltage, sisan, funteni abnormal lakanani(minɛn dɔw bɛ), ani abnormal alarma, supportbattery overcharge, overdischarge lakanani sɛgɛsɛgɛli

7. dɛmɛni kanal paralɛli (a bɛ se ka kɛ ka kɛɲɛ ni thedevice ye);

8. dɛmɛni unit caman tigɛli ;

9. dɛmɛ don database server kɔkanna marali walima MESdocking;

10. porogaramuw lakanani minnu tɛ ɛntɛrinɛti kan;

11. porogaramuw walasa ka sɛgɛsɛgɛli kɛ fu.

12. dɛmɛ don sɛbɛnni labeli bɔli suguya caman na

Kalan karti sensɛri RFlD baarakɛcogo

Wajibi tɛ

Tiɲɛni latilenni sɛrɛkili

Tile 180 -tile 360

Jateminɛ kɛcogo

Porozɛw ka jateminɛ kɛcogo otomatiki

Calibration baarakɛminɛn

1 set of high precision calibration tooling ye fɛn ye min bɛ se ka kɛ

Sigida kɔlɔsili ɔridinatɛri

Labɛnni wajibiyalenw: (baarakɛla ta) .

1. Baarakɛminɛn: Windows 7 walima kɔfɛ Sinuwakan: Sinuwakan nɔgɔman

2. CPU: i5 bɔnsɔn 9 walima a sanfɛ

3. Hakilila: a ka ca ni 8GB ye

4. Disiki gɛlɛn: 500G walima ka tɛmɛ o kan

5. Monitor: LCD monitor min janya ye santimɛtɛrɛ 21 ye walima a sanfɛ

6. Karti fila bɛ sɔrɔ rezow kɔnɔ
